5 Ton Pneumatic Air Winch | Explosion-Proof Winch Manufacturer
⭐ Key Features
- Explosion-proof, dust-proof and liquid splash-proof design for harsh environments
- Flexible forward and backward movement with stepless speed control
🛠️ Service
📋 Product Specifications
| Model Number | QJH5 |
|---|---|
| Model | QJH5 |
| Rated Line Pull | 5 kN |
| Rated Line Pull (Ton) | 0.5 ton |
| Rope Speed | 48 m/min |
| Rope Diameter | 8 mm |
| Rope Capacity | 90 m |
| Air Pressure | 0.69 Mpa |
| Overall Dimensions | 683*410*490 mm |
| Weight | 117 kg |
| Control | Remote Control |
📄 Product Description
Product Introduction
The pneumatic air winch is a kind of winch powered by compressed gas supplied by air compressor. It is divided into piston air winch and blade air winch. Compared with the traditional electric winch, the pneumatic winch has the characteristics of explosion-proof, dust-proof and liquid splash-proof, and can adapt to work in harsh environments. Therefore, the pneumatic winch is widely used in ships, oil exploitation, mining and electric power and other industries.
Key Features
- Explosion-proof function, reliable operation under inflammable and explosive environment
- High starting torque enables start with load, with anti-overload function
- Small size, light weight, and mobility for easy installation
- Flexible forward and backward movement, stepless speed control
- Safe operation under high wet and damp conditions
Applications
The pneumatic winch is widely used in ships, oil exploitation, mining, electric power industries and work places with flammable gas. It can be used to lift and pull heavy objects in land drilling, ocean platform drilling, mine drilling, and other harsh environments where explosion-proof performance is required.
Quality Assurance
| Item | Standard |
|---|---|
| Certification | CE / ISO 9001 |
| Working Duty | A3-A5 |
| Warranty | 1 Year |
